Technical Specifications
Speed: 2x11-speed
Action Design: Side-Swing (front-pull cable routing)
Top Gear Teeth: 34T-38T
Total Capacity: 10T
Chain Line: 48.8 mm (compatible with special cranksets with a chainline 3 mm outboard)
Chain Stay Angle: 66-69
Compatible Chain: HG-X11
Mounting Options
Direct Mount (FD-M8020-D): Bolts directly to frame mounts
E-Type Mount (FD-M8020-E): Mounts via an E-type plate near the bottom bracket
Clamp-On (High/Low Clamp, FD-M8020-H/L): Fits seat tube diameters of 34.9 mm, with adapters available for 28.6 mm and 31.8 mm
