SIZES
S, M, L, XL
MODEL CODE
G23400M
FRAME
Force Alloy 27.5" frame, 150mm Travel, BSA 73mm, LockR Pivots, Tapered Head Tube, Boost 12x148 Thru-Axle, 185x55mm Trunnion Shock Mount, ISCG05
FORK
RockShox Lyrik Select RC, 160mm, Charger Damper, BOOST 15x110mm, tapered steerer, 46mm offset
REAR SHOCK
RockShox Select+ RL, 185x55mm, Metric Trunnion
CHAIN
KMC X11, 11-speed
CRANK
Prowheel, 30T, 170mm(S-L), 175mm(XL)
BOTTOM BRACKET
Prowheel BSA
PEDALS
Not Included
REAR DERAILLEUR
SRAM NX
SHIFTERS
SRAM NX, 11-speed
COG SET
Sunrace, 11-42, 11-speed
RIMS
WTB ST i29 TCS 2.0, 32h, tubeless ready
TIRES
Schwalbe Hans Dampf Performance, 27.5 x 2.35", TwinSkin, Addix Compound, tubeless ready Schwalbe Hans Dampf Performance, 27.5 x 2.35", TwinSkin, Addix Compound, tubeless ready
WHEELS SIZE
27.5"
FRONT HUB
Formula 15x110
SPOKES
Stainless Steel, 14g
BRAKES
Tektro M745 hydro disc, 203/180mm rotors
FRONT BRAKE
Tektro M745 hydro disc, 203/180mm rotors
REAR BRAKE
Tektro M745 hydro disc, 203/180mm rotors
BRAKE LEVERS
Tektro M745
HANDLEBAR
GT Alloy riser bar, 15mm rise, 780mm width
STEM
GT Alloy Stem, 31.8mm Clamp, 45mm Length
GRIPS
GT Statement2 Double Lock-on Grips
HEADSET
FSA NO.42, Semi Integrated, Sealed Bearing, Tapered
SADDLEWTB
Silverado Sport, steel rails
SEAT POST
TranzX Dropper, 31.6, Internal Routing, 120mm (S,M), 150mm (L,XL)
